Electrical Measurement Techniques
For the Physics Laboratory
Samenvatting
This book highlights the electrical engineering aspects of a typical physics laboratory. To perform a sound experiment in a physics laboratory, it is paramount that readers understand the equipment and methods used to collect the data.
This includes sensors (e.g., thermocouples and vacuum gauges), amplifiers (e.g., instrumentation amplifiers and lock-in amplifiers), oscilloscopes and probes (active probes and current probes), transmission cables (50-ohm termination) and noise shielding (grounding), spectrum analyzers (FFT and heterodyne technique), ADCs and digital signal processing, convolution and correlation, data analysis such as curve fitting, and uncertainty calculations (uncertainty ‘budgets’).
The readers need to know about electromagnetic crosstalk, time-to-digital converters, student-t distributions, PID controllers, spectral leakage, and windows. This book helps readers understand all of that.
Specificaties
Inhoudsopgave
Chapter 2. Noise: Sources and remedies.
Chapter 3. Sensors.
Chapter 4. The instrumentation amplifier.
Chapter 5. Transmission lines.
Chapter 6. Probes.
Chapter 7. Transform theory.
Chapter 8. Spectral analyzers.
Chapter 9. Analog filters.
Chapter 10. Digital filters.
Chapter 11. ADCs and sampling.
Chapter 12. Time-to-digital converters.
Chapter 13. Statistics.
Chapter 14. Uncertainty budgets.
Chapter 15. The lock-in amplifier.
Chapter 16 Correlation.
Chapter 17. Curve fitting.
Chapter 18. Introduction to control theory.
Appendix.- A Operational amplifiers.
Index.
