Analysis of Electrical Circuits with Variable Load Regime Parameters
Projective Geometry Method
Samenvatting
This book introduces electric circuits with variable
loads and voltage regulators. It allows to define invariant relationships for
various parameters of regime and circuit sections and to prove the concepts
characterizing these circuits. The book presents the fundamentals of electric
circuits and develops circuit theorems. Generalized equivalent circuits
are introduced. Projective geometry is used for the interpretation of changes
of operating regime parameters. Expressions of normalized regime parameters and
their changes are presented. Convenient formulas for the calculation of
currents are given. Parallel voltage sources and the cascade connection of
multi-port networks are described. The two-value voltage regulation
characteristics of loads with limited power of voltage source is considered.
This second edition is extended and contains additional chapters on circuits with
non-linear regulation curves, circuits with non-linear load characteristics,
concepts of power-source and power-load elements with two-valued
characteristics, quasi-resonant voltage converters with self-limitation of
current as well as the similarity of characteristics of converters and
electronic devices.
This book is useful to engineers, researchers and
graduate students who are interested in the basic electric circuit theory and
the regulation and monitoring of power supply systems.
Specificaties
Inhoudsopgave
- Projective Coordinates of
a Straight Line Point.- Operating Regimes
of an Active Two-Pole. Display of Projective Geometry.- Generalized Equivalent
Circuit of an Active Two-Pole with a Variable element.- Two-Port Circuits.- Paralleling
of Limited Capacity Voltage Sources.- Part II : Multi-port Circuits - Projective Coordinates of a Point on the Plane
and Space.- Operating Regimes of an Active Multi-port.- Recalculation of Load Currents
of Active Multi-ports.- Passive Multi-Port
Circuits.- Generalized
Equivalent Circuit of a Multi-port.- Part III: Circuits with Non-Linear
Regulation Curves.- Regulation of Load Voltages.- Stabilization of Load
Voltages.- Pulse-Width Modulation Regulators.- Part IV: Circuits with
Non-Linear Load Characteristics.- Power-Source and Power-Load Elements.- Quasi-Resonant
Voltage Converter with Self-Limitation of the Load Current. Similarity of Load
Characteristics of Some Electronic Devices.- Conclusions.</p>
