Zinc Oxide - A Material for Micro- and Optoelectronic Applications
Proceedings of the NATO Advanced Research Workshop on Zinc Oxide as a Material for Micro- and Optoelectronic Applications, held in St. Petersburg, Russia, from 23 to 25 June 2004
Samenvatting
Recently, a significant effort has been devoted to the investigation of ZnO as a suitable semiconductor for UV light-emitting diodes, lasers, and detectors and hetero-substrates for GaN. Research is driven not only by the technological requirements of state-of-the-art applications but also by the lack of a fundamental understanding of growth processes, the role of intrinsic defects and dopants, and the properties of hydrogen. The NATO Advanced Research Workshop on “Zinc oxide as a material for micro- and optoelectronic applications”, held from June 23 to June 25 2004 in St. Petersburg, Russia, was organized accordingly and started with the growth of ZnO. A variety of growth methods for bulk and layer growth were discussed. These techniques comprised growth methods such as closed space vapor transport (CSVT), metal-organic chemical vapor deposition, reactive ion sputtering, and pulsed laser deposition. From a structural point of view using these growth techniques ZnO can be fabricated ranging from single crystalline bulk material to polycrystalline ZnO and nanowhiskers. A major aspect of the ZnO growth is doping. n-type doping is relatively easy to accomplish with elements such al Al or Ga. At room temperature single crystal ZnO exhibits a resistivity of about 0. 3 -cm, an electron mobility of 2 17 -3 225 cm /Vs, and a carrier concentration of 10 cm . In n-type ZnO two shallow donors are observable with activation energies of 30 – 40 meV and 60 – 70 meV.
Specificaties
Inhoudsopgave
Hydrogen-Related Defects in Zno Studied by JR Absorption Spectroscopy; E.V. Lavrov et al. Influence of the Hydrogen Concentration on H Bonding in Zinc Oxide; N.H. Nickel. Part IV: Fundamental properties: Valence Band Ordering and Magneto-Optical Properties of Free and Bound Excitons in ZnO; A.V. Rodina et al. Fundamental Optical Spectra and Electronic Structure of Zno Crystals; V. Val et al. Photo-Induced Localized Lattice Vibrations in ZnO Doped with 3d Transition Metal Impurities; Alexey Kislov. Part V: Device applications: ZnO Window Layers for Solar Cells; W. Fuhs. ZnO/AlGaN Ultraviolet Light Emitting Diodes; E.V. Kaunina et al. ZnO Transparent Thin-Film Transistor Device Physics; J.F. Wager. Zinc Oxide Thin Film Transistors; E. Fortunato et al. Index
