Paul Green
Elsevier Science
e druk, 2005
9780750668217
The Geometrical Tolerancing Desk Reference
Creating and Interpreting ISO Standard Technical Drawings
Specificaties
Paperback, blz.
|
Engels
Elsevier Science |
e druk, 2005
ISBN13: 9780750668217
Rubricering
Levertijd ongeveer 8 werkdagen
Samenvatting
Geometrical tolerancing is the standard technique that designers and engineers use to specify and control the form, location and orientation of the features of components and manufactured parts. This innovative book has been created to simplify and codify the use and understanding of geometrical tolerancing. It is a complete, self contained reference for daily use. An indispensable guide for anyone who creates or needs to understand technical drawings.
Specificaties
Inhoudsopgave
Preface; ISO/ANSI/BS text equivalents; New ISO terminology; Introduction to Engineering Drawing; How to use this book; Single features; Symbols; Tolerance frame; Datum symbols; Datum target; Toleranced feature; Tolerance zone; True dimensions; Projected tolerance zone; Maximum material condition; Least material condition; Envelope requirement; Screw threads, gears and splines; Principle of independency; General tolerances; Geometrical tolerancing examples; Quick reference tables; Index
